Server Dell PowerEdge R740XD 12x3.5" with 2x Platinum 8160, 64GB RAM, H730P, 2x 480GB SSD SATA 2.5", 4x1GbE, 2xPSU, Rails, iDRAC 9 Enterprise
Manufacturer: Dell
PN: R740XD-12x3.5-2x8160-64GB-H730P-V01
Loading...
Calculating delivery time...In stock: 4
Warranty: 36 months with the possibility of extension
- 1x Dell PowerEdge R740XD 12x3.5" server platform
- 2x Intel Xeon Platinum 8160 24-core 2.1GHz 33MB 150W SR3B0 processor
- 4x RAM 16GB DDR4 2666MHz RDIMM
- 2x 480GB SSD SATA 2.5" hard drive
- 2x 3.5" drive tray
- 2x Dell adapter for 2.5" drive to 3.5" tray
- 1x Dell PERC H730P 2GB Mini mono RAID controller
- 1x Dell 4x1GbE rNDC network card
- 2x Dell power supply
- 1x Rail kit
Technical information about the R740xd model line of servers
- Server height: 2U
- Server depth: 71cm
- Server weight: 41kg
- Chassis types: 24x2.5", 12x3.5"
- Number of processors: maximum 2 x CPU 2nd Generation Intel Xeon Scalable processors(acceptable configurations: 1 or 2 processors)
- Maximum number of processor cores: 2x 28-core / 56-thread CPU total 56-core / 112-thread
- Number of RAM banks: 24 DDR4
- Maximum RAM size: 24x128GB DDR4 RDIMM total 3TB
- Number of drive bays: 24x2.5", 12x3.5"
- Motherboard chipset: Intel C610
- Number of USB ports: 5 (2x front, 2x back, 1x inside)
- Number of PCI-E slots: up to 8x PCIe Gen 3
- Maximum number of power supplies: 2
- Supported power supplies: 495W, 750W, 1100W or 1600W
- Remote management: iDRAC 9
- Supported internal RAID controllers: H330, PERC H730P, PERC H740P, HBA330, S140 and BOSS cards
Optional accessories for the R740xd server
The server can be additionally equipped with optional accessories:
- Cable organizer
- Empty hard drive pockets
- Front panel / bezel / bezel
- Power cables
- PCI-E expansion cards
All additional accessories you will find in our offer.
Together with the server it is possible to purchase the operating system
- Windows Server Standard
- Windows Server Essentials
- Windows Server Data Center
- VMWare (ESXi, vSphere, vSAN)
- other software, for example SQL Server
When you buy this server from Hardware Direct, you can be sure that:
- The server is thoroughly tested, 100% operational and ready to continue working for a long time
- The server is restored to factory settings and updated to the latest firmware versions - you are assured that there will be no problems with its use after the upgrade itself
- You are buying the server from an official Dell partner with professional server hardware service
- The server is sold with a premium Next Business Day service contract. In case of failure, we are the first to deliver the replacement hardware to you. More details in the corresponding tab.
ATTENTION!
Photos are for reference only, some elements of the server configuration such as risers may differ from those shown in the photos.
Specifications
| Manufacturer | Dell |
|---|---|
| Compatible with | PowerEdge R740xd 12x3.5" |
| Core Count | 24 |
| Number of 1GbE RJ45 ports | 4 |
| Number of 10GbE SFP+ ports | 0 |
| Number of 10GbE BASE-T ports | 0 |
| Number of 40GbE QSFP+ ports | 0 |
| Number of 10/25GbE SFP28 ports | 0 |
| Number of 8Gb FC ports | 0 |
| Number of 16Gb FC ports | 0 |
| CPU Cores | 48 |
| Suma mocy zasilaczy | 990 W |
| Single CPU PassMark score | 26485 |
| CPU Base Frequency | 2 GHz |
| Ilość zainstalowanych procesorów | 2 |
| Ilość wątków | 96 |
| Ilość wątków w procesorze | 48 |
| Częstotliwość turbo taktowania procesora | 3 GHz |
| TDP procesora | 150 W |
| Ilość portów 32Gb FC | 0 |
| Ilość zainstalowanych zasilaczy | 2 |
| Klasa sprawności zasilacza | 80+ Platinum |
| RAM Capacity | 64 GB |
| Depth | 43 cm |
