Technical information about the R740xd2 server model line.
Server height: 2U
Server depth: 71cm
Server weight: 40kg
Chassis types: 24x2.5"
Number of processors: maximum 2 x CPU 2nd Generation Intel Xeon Scalable processors(acceptable configurations: 1 or 2 processors)
Maximum number of processor cores:: 2x 22-core / 44-thread CPU total 44-core / 88-thread
Number of RAM banks: 16 DDR4
Maximum RAM size: 16x128GB DDR4 RDIMM total 2TB
Number of drive bays: 24x2.5"
Motherboard chipset: Intel C621
Number of USB ports: 5 (2x front, 2x back, 1x inside)
Number of PCI-E slots: up to 5x PCIe Gen 3
Maximum number of power supplies:: 2
Supported power supplies: 750W or 1100W
Remote management: iDRAC 9
Supported internal RAID controllers: H330, PERC H730P, PERC H740P, HBA330, S140 and BOSS cards
Optional accessories for the R740xd2 server
The server can be further equipped with optional accessories:
Cable organizer
Empty hard drive bays
Front panel / bezel / bezel
Power cables
PCI-E expansion cards
All additional accessories you will find in our offer.
Razem z serwerem możliwy jest zakup systemu operacyjnego
Windows Server Standard
Windows Server Essentials
Windows Server Data Center
VMWare (ESXi, vSphere, vSAN)
other software such as SQL Server
When you buy this server from Hardware Direct, you can rest assured that:
The server is thoroughly tested, 100% operational and ready for continued long term operation
She server is restored to factory settings and updated to the latest firmware versions - you are assured that there will be no problems with its use after the upgrade itself
You are buying the server from an official Dell partner with professional server hardware service
The server is sold with a premium Next Business Day contract. In case of failure, we are the first to deliver the replacement hardware to you. More details in the corresponding tab.
Attention!
Photos are for reference only, some elements of the server configuration such as risers may differ from those shown in the photos.
Specifications
More Information
Manufacturer
Dell
Compatible with
PowerEdge R740xd2 24x3.5"
Core Count
4
Chassis type
Obudowa Rack 2U
CPU Cores
8
Suma mocy zasilaczy
990 W
Single CPU PassMark score
6420
CPU Base Frequency
2 GHz
Ilość zainstalowanych procesorów
2
Maksymalna ilość procesorów
2
Ilość wątków
16
Ilość wątków w procesorze
8
Częstotliwość turbo taktowania procesora
3 GHz
TDP procesora
85 W
Ilość zainstalowanych zasilaczy
2
Klasa sprawności zasilacza
80+ Platinum
RAM Capacity
128 GB
