Server Dell C4140 with 2x Gold 5222, Card BOSS with 2x240GB SSD SATA, 2xPSU, Rails
Manufacturer: Dell
PN: C4140-2x5222-32GB-V01
Available for pickup on Wednesday 10:00
In stock: 1
Warranty: 36 months with the possibility of extension
This set contains:
- 1x Dell PowerEdge C4140 1U 2xGPU Server Platform
- 2x Intel Xeon Gold 5222 4-core 3.8GHz 16.5MB 105W SRF8V processor
- 2x RAM 16GB 2400MHz DDR4 RDIMM
- 1x BOSS SATA Adapter 2xM.2 2280 Card
- 2x 240GB SSD SATA 6G M.2 hard drive
- 1x Dell Intel X520/i350 2x1GbE 2x10GbE SFP+ 2.0x8 RNDC Network interface card
- 2x Dell power supply
- 1x Rails kit
Technical information about Dell PowerEdge C4140 server
- Server height: 1U
- Server depth: 93cm
- Maximum server weight: 24kg
- Chassis types: Diskless
- Number of processors: maximum 2 x Intel Xeon Scalable (acceptable configurations: 1 or 2 processors)
- Maximum number of processor cores: 2x 20-core / 40-thread CPU total 40-core / 80-thread
- Number of RAM banks: 24 DDR4
- Maximum RAM size: 24x128GB DDR4 RDIMM total 3TB
- Number of drive bays: Diskless
- Motherboard chipset: Intel C612
- Number of USB ports: 3 (2x on the back, 1x in the middle)
- Number of PCI-E slots: 3x PCI-E gen 3
- Number of PCI-E slots for graphics cards: 4
- Maximum number of power supplies: 2
- Supported power supplies: 2000W or 2400W
- Remote management: iDRAC 9
- Supported internal RAID controllers: PERC H330, H730, H730P or H810
- Supported graphics cards: NVIDIA Tesla P40, P100, V100
Optional accessories for the C4140 server
The server can be further equipped with optional accessories:
- Cable organizer
- Power cables
- PCI-E expansion cards
All additional accessories you will find in our offer.
Together with the server it is possible to purchase the operating system
- Windows Server Standard
- Windows Server Essentials
- Windows Server Data Center
- VMWare (ESXi, vSphere, vSAN)
- other software such as SQL Server
When you buy this server from Hardware Direct, you can rest assured that:
- The server is thoroughly tested, 100% operational and ready for continued long term operation
- The server is restored to factory settings and updated to the latest firmware versions - you are assured that there will be no problems with its use after the upgrade itself
- You are buying the server from an official Dell partner with professional server hardware service
- The server is sold with a premium Next Business Day service contract. In case of failure, we are the first to deliver the replacement hardware to you. More details in the corresponding tab.
ATTENTION!
Photos are for reference only, some elements of the server configuration such as risers may differ from those shown in the photos.
Specifications
| Manufacturer | Dell |
|---|---|
| Compatible with | PowerEdge C4140 |
| Core Count | 4 |
| Number of 1GbE RJ45 ports | 2 |
| Number of 10GbE SFP+ ports | 2 |
| Number of 10GbE BASE-T ports | 0 |
| Number of 40GbE QSFP+ ports | 0 |
| Number of 10/25GbE SFP28 ports | 0 |
| Number of 8Gb FC ports | 0 |
| Number of 16Gb FC ports | 0 |
| Chassis type | Obudowa Rack 1U |
| CPU Cores | 8 |
| Suma mocy zasilaczy | 4000 W |
| Single CPU PassMark score | 9428 |
| CPU Base Frequency | 3 GHz |
| Ilość zainstalowanych procesorów | 2 |
| Ilość wątków | 16 |
| Ilość wątków w procesorze | 8 |
| Częstotliwość turbo taktowania procesora | 3 GHz |
| TDP procesora | 105 W |
| Ilość portów 32Gb FC | 0 |
| Ilość zainstalowanych zasilaczy | 2 |
| Klasa sprawności zasilacza | 80+ Platinum |
| RAM Capacity | 32 GB |
