Server Dell PowerEdge R640 4x3.5" z 2x Silver 4309Y, 64GB RAM, P408i-a, 2x480GB SSD SATA RI 2.5", 2x10GbE SFP+, 2x PSU 800W, rails, iLO 5 Standard

Technical information about the DL360 Gen10 Plus model line of servers

• Server height: 1U
• Server depth: 77cm
• Server weight: 20kg
• Chassis types: 8x2.5 or 4x3.5
• Number of processors: maximum 2 x CPU 3nd Generation Intel Xeon Scalable processors(acceptable configurations: 1 or 2 processors)
• Maximum number of processor cores 2x 40-core / 80-thread CPU total 80-core / 160-thread
• Number of RAM banks: 32 DDR4
• Maximum RAM size: 32x128GB DDR4 RDIMM total 4TB
• Number of drive bays: 8x2.5" or 4x3.5
• Motherboard chipset: Intel C621A
• Number of USB ports: 5 (1x front, 2x rear, 2x inside)
• Number of PCI-E slots: up to 3x PCIe Gen 4
• Maximum number of power supplies: 2
• Supported power supplies: 500W, 800W, 1000W, 1600W, 1800W or 2200W
• Remote management: iLO5 Advanced
• Supported internal RAID controllers: SR100i, MR216i-a, MR216i-p, SR416i-a, MR416i-a, MR416i-p, SR932i-p, E208i-a, E208i-p, P408i-a, P408i-p or P816i-a

Optional accessories for the DL360 Gen10 Plus server

The server can be further equipped with optional accessories:

• Cable organizer
• Empty hard drive bays
• Front panel / bezel / bezel
• Power cables
• PCI-E expansion cards

All additional accessories you will find in our offer.

Together with the server it is possible to purchase the operating system

• Windows Server Standard
• Windows Server Essentials
• Windows Server Data Center
• VMWare (ESXi, vSphere, vSAN)
• other software such as SQL Server

When you buy this server from Hardware Direct, you can rest assured that:

• The server is thoroughly tested, 100% operational and ready for continued long term operation
• The server is restored to factory settings and updated to the latest firmware versions - you are assured that there will be no problems with its use after the upgrade itself
• The server is sold with a premium Next Business Day service contract. In case of failure, we are the first to deliver the replacement hardware to you. For more details, please see the corresponding tab.

Attention!

Photos are for reference only, some elements of the server configuration such as risers may differ from those shown in the photos.
